ML132

Caspase 1

研究人员检查了VRT-043198（2b）、ML132 (NCGC 00185682)（3）、NCGC00183434（4）和四唑NCGC00183681（16），结果如图2所示。VRT-043198（2b）被证实是一种有效的胱天蛋白酶1抑制剂，IC50值为11.5 nM。发现含有关键氰基丙酸酯部分的NCGC00183434（4）以0.316 nM的IC50值抑制胱天蛋白酶1。我们还满意地发现，与胱天蛋白酶1相比，乙酯3和四唑16保留了令人印象深刻的效力（IC50=144.7nM和IC50=20.4 nM）。使用竞争性抑制模型[1]，胱天蛋白酶1的KI值4估计为0.4 nM。

Based upon the data provided in this panel, it was clear that these agents represent important new tools for caspase 1 inhibition. However, the contributing functional groups for these agents (i.e. ethyl acetals, aldehydes, nitriles and esters) are all subject to hydrolysis in various conditions. It was paramount to fully understand their stability profile to appreciate their utility as molecular probes or even clinically used agents. Therefore, we examined 1, 2b, 3/ML132 (NCGC 00185682), 4 and 16 within an aqueous degradation study at neutral (pH 7), acidic (pH 2), and basic (pH 8) conditions. The study was conducted by monitoring the degradation of each agent by LCMS analysis at various time points over 96 hours (Figure 3). The prodrug 1 showed moderate degradation in water with over 50% of the compound decomposed after 48 hours. This degradation was amplified in both basic and acidic conditions. Conversely, the active agent 2b was very stable in both neutral and acidic conditions and its degradation at pH 8 was moderate. The potent 4 was exceedingly stable in basic conditions and its stability in neutral and acidic conditions was moderate to good (degradation of 50% in both conditions after 72 hours). The ethyl ester 3/ML132 (NCGC 00185682) was exceptionally stable in neutral and acidic conditions (no degradation noted), however, it was fully degraded in basic conditions after 22 hours (presumably due to saponification of the ester). Finally, the tetrazole 16 was found to be resistant to degradation in all conditions. Interestingly, this data suggests that 1 may have a short half-life as an oral agent due to its instability in acidic conditions such as those found in the gastric environment (40% degradation after 3.5 hours at pH 2). In contrast, this data highly suggests that 3/ML132 (NCGC 00185682) and 16 will be suitable reagents for all manner of examinations (cell based and in vivo studies) and even the highly active 4 will persist beyond 24 hours.[1]

[1]. A highly potent and selective caspase 1 inhibitor that utilizes a key 3-cyanopropanoic acid moiety. ChemMedChem.2010 May 3;5(5):730-8.

(3S)-3-[[[(2S)-1-[(2S)-2-[[(4-amino-3-chlorophenyl)-oxomethyl]amino]-3,3-dimethyl-1-oxobutyl]-2-pyrrolidinyl]-oxomethyl]amino]-3-cyanopropanoic acid is a peptide.

---

Herein, we examine the potential of a nitrile-containing propionic acid moiety as an electrophile for covalent attack by the active-site cysteine residue of caspase 1. The syntheses of several cyanopropanate-containing small molecules based on the optimized peptidic scaffold of prodrug VX-765 were accomplished. These compounds were found to be potent inhibitors of caspase 1 (IC(50) values < or =1 nM). Examination of these novel small molecules against a caspase panel demonstrated an impressive degree of selectivity for caspase 1 inhibition over other caspase isozymes. Assessment of hydrolytic stability and selected ADME properties highlighted these agents as potentially useful tools for studying caspase 1 down-regulation in various settings, including in vivo analyses. [1]

C22H28CLN5O5

477.941224098206

477.177

C, 55.29; H, 5.90; Cl, 7.42; N, 14.65; O, 16.74

1230628-71-3

44620939

White to light yellow solid powder

1.6

166

4

7

8

33

820

3

ClC1=C(C=CC(=C1)C(N[C@H](C(N1CCC[C@H]1C(NC[C@@H](C#N)C(=O)O)=O)=O)C(C)(C)C)=O)N

KENKPOUHXLJLEY-QANKJYHBSA-N

InChI=1S/C22H28ClN5O5/c1-22(2,3)18(27-19(31)12-6-7-15(25)14(23)9-12)21(33)28-8-4-5-16(28)20(32)26-13(11-24)10-17(29)30/h6-7,9,13,16,18H,4-5,8,10,25H2,1-3H3,(H,26,32)(H,27,31)(H,29,30)/t13-,16-,18+/m0/s1

2934.99.9001

Powder      -20°C    3 years

                     4°C     2 years

In solvent   -80°C    6 months

                  -20°C    1 month

注意： (1). 本产品在运输和储存过程中需避光。  (2). 请将本产品存放在密封且受保护的环境中（例如氮气保护），避免吸湿/受潮。

Room temperature (This product is stable at ambient temperature for a few days during ordinary shipping and time spent in Customs)

配方 1 中的溶解度: ≥ 7 mg/mL (14.65 mM) (饱和度未知) in 10% DMSO + 90% (20% SBE-β-CD in Saline) (这些助溶剂从左到右依次添加，逐一添加), 澄清溶液。
例如，若需制备1 mL的工作液，可将100 μL 70.0mg/mL澄清的DMSO储备液加入到900μL 20％SBE-β-CD生理盐水中，混匀。
*20% SBE-β-CD 生理盐水溶液的制备（4°C，1 周）：将 2 g SBE-β-CD 溶解于 10 mL 生理盐水中，得到澄清溶液。

---

配方 2 中的溶解度: ≥ 6.25 mg/mL (13.08 mM) (饱和度未知) in 10% DMSO + 40% PEG300 + 5% Tween80 + 45% Saline (这些助溶剂从左到右依次添加，逐一添加), 澄清溶液。
例如，若需制备1 mL的工作液，可将 100 μL 62.5 mg/mL澄清的DMSO储备液加入到400 μL PEG300中，混匀；再向上述溶液中加入50 μL Tween-80，混匀；然后加入450 μL生理盐水定容至1 mL。
*生理盐水的制备：将 0.9 g 氯化钠溶解在 100 mL ddH₂O中，得到澄清溶液。

---

View More

配方 3 中的溶解度: ≥ 6.25 mg/mL (13.08 mM) (饱和度未知) in 10% DMSO + 90% Corn Oil (这些助溶剂从左到右依次添加，逐一添加), 澄清溶液。
例如，若需制备1 mL的工作液，可将 100 μL 62.5 mg/mL 的澄清 DMSO 储备液加入到 900 μL 玉米油中并混合均匀。

---

请根据您的实验动物和给药方式选择适当的溶解配方/方案：
1、请先配制澄清的储备液(如：用DMSO配置50 或 100 mg/mL母液(储备液));
2、取适量母液，按从左到右的顺序依次添加助溶剂，澄清后再加入下一助溶剂。以 下列配方为例说明 (注意此配方只用于说明，并不一定代表此产品 的实际溶解配方):
10% DMSO → 40% PEG300 → 5% Tween-80 → 45% ddH2O (或 saline);
假设最终工作液的体积为 1 mL, 浓度为5 mg/mL: 取 100 μL 50 mg/mL 的澄清 DMSO 储备液加到 400 μL PEG300 中，混合均匀/澄清；向上述体系中加入50 μL Tween-80，混合均匀/澄清；然后继续加入450 μL ddH2O (或 saline)定容至 1 mL；
3、溶剂前显示的百分比是指该溶剂在最终溶液/工作液中的体积所占比例;
4、 如产品在配制过程中出现沉淀/析出，可通过加热(≤50℃)或超声的方式助溶;
5、为保证最佳实验结果，工作液请现配现用！
6、如不确定怎么将母液配置成体内动物实验的工作液，请查看说明书或联系我们;
7、 以上所有助溶剂都可在 Invivochem.cn网站购买。
